The owners and operators of tunnel-style vehicle washes are under constant pressure to optimize the amount of cleaning chemicals and water that are consumed by their wash systems. This pressure can come from many different sources: regulatory, budgetary, and operational chief among them.
Ironically, in order to ease the pressure on wash operators, Hydro™ has decided to increase the pressure, namely through the capabilities of its new HydroMinder™ HP, a High-Pressure Chemical-Dispensing Unit. The HydroMinder HP is a venturi-injector-based multi-channel chemical dilution and proportioning system that has been specifically designed to meet the needs of tunnel-wash operators who are looking to improve the efficiency and overall expense of their chemical-dispensing tasks.
The “source to suds” capabilities of the HydroMinder HP enables wash operators to confidently reduce chemical waste in their operations so that they can optimize the overall performance of their businesses. HydroMinder HP’s patented metering tips help enable 95% accurate dilution control for cleaner vehicles, precise distribution of chemicals, and more efficient water consumption. The operational efficiency of the metering tips allows the spraying of smaller chemical droplets, resulting in more consistent chemical disbursement and coverage that eliminates the need for manually adjusted dials.
In fact, internal laboratory testing of the HydroMinder HP revealed that its chemical-dilution performance is 11% more accurate when compared to competitive systems. Additionally, in-the-field testing of the HydroMinder HP indicates that wash operators can see up to a 23% reduction in chemical costs when deploying the system.
The HydroMinder HP has been designed to provide unstoppable control as it essentially never needs to be shut down to change valves or change out chemicals, resulting in negligible downtime that can hamper throughput rates on busy wash days. The unit’s design allows for five or seven single-sized quick-connect valves per panel with a variety of injector assemblies available. This allows easy system configuration with the capability to produce injection rates up to 20 gallons per minute (gpm) at 200 pounds per square inch (psi) of pressure. Each injector is ready to pump chemicals upon installation and has been designed to work with most common trigger voltages, including 24 VAC, 24 VDC and 110V.
Knowing the demands of operating in tough, oftentimes corrosive and aggressive vehicle-wash environments, the system’s injectors are made from Kynar® PVDF, which helps ensure maximum chemical resistance while improving longevity and reducing maintenance costs. The HydroMinder HP’s back panel, water valve bodies and manifold fascia are constructed of 304 stainless steel, which is highly corrosion resistant. Also, the unit’s chemical pump features full stainless-steel construction with a stainless-steel housing and impellers.
The HydroMinder HP’s pump is a vertical multi-stage floor-mounted device that is self-priming and features a coupling connection between the pump and motor. The pump is controlled by a standard variable frequency drive (VFD) and 300-psi transducer. The pump also includes connections for plumbing, filter kit and hose, and is available in 230V and 480V three-phase configurations.
So, if you’re feeling pressure to optimize chemical usage and cost within your tunnel-wash system, visit hydrosystemsco.com to learn how the HydroMinder™ HP High-Pressure Chemical-Dispensing Unit from Hydro can help relieve that pressure.
Call 1-800-543-7184 Monday-Friday 8am - 5pm EST
